Highlight

From breakaways to the final sprint. On flat roads, climbs or descents. The reengineered Propel Advanced SL cuts through wind and maximises watts, optimising your energy through every dimension of speed: top-end speed, instant speed and sustained speed.

KEY PERFORMANCE FACTORS

INSTANT SPEED

In the moments when explosive speed matters most—launching an attack, chasing a break, or sprinting for the finish line—the new Propel Advanced SL is quicker and more dynamic than ever. The new frameset is more efficient with 14.2% more torsional stiffness and 14.8% greater pedalling stiffness—so you feel instantaneous reaction when you make your move.

SUSTAINED SPEED

Engineered for full-bike compliance, the new Propel Advanced SL frameset delivers a significantly smoother ride when you’re rolling in the group or piling up training miles. The Vector integrated seatpost has 25% greater compliance compared to the previous generation. The fork helps absorb bumps and vibrations up front. And additional tyre clearance allows for high-volume tyres up to 32mm, further smoothing out the ride to help you maintain higher speeds with less fatigue.

TOP-END SPEED

The frameset, including the frame, fork, Vector integrated seatpost, and aero bottle cages, are designed to be part of a system to lower total resistance when you’re pushing high speeds in the wind—whether you’re on a solo break, taking pulls at the front, or powering away on a climb. OverDrive Aero technology includes a slim, tapered head tube paired seamlessly with a D-shaped fork steerer tube and spacers. Brake and shifter cables can be internally routed through the frame and fork, keeping them hidden from the wind.

SPECIFICATIONS

Sizes

XS, S, M, ML
Colors

Nitro Purple
Frame

Advanced SL-grade Composite, 12x142mm thru-axle, UDH compatible, integrated seatpost, disc, 142x12mm Pitch 1.0
Fork

Advanced SL-grade composite, full-composite OverDrive Aero steerer, 12x100mm thru-axle, disc, 100x12mm Pitch 1.5
Seatpost
Advanced SL-grade composite, integrated design, -5/+15mm offset
Bottom Bracket

BB86 accepts press fit style BB only, bearing set not included
Extras
20mm & 45mm ISP clamps. ISP spacers (2x10mm, 1x5mm, 1x2.5mm, 2x1mm). Bottle cages, 32mm max tyre size

*All specifications and prices listed are subject to change without notice.
**Price does not include handlebar and stem

Sizing Guide and Geometry

Sizing to be used as a reference only. Please check with a local authorized dealer to determine the correct size.
Available sizes may vary by country.

Propel Adv SL (4th Gen)

		XS	S	M	ML	L	XL
A	Seattube length	680	710	740	770	800	830
B	Seattube angle (degrees)	74.50	74.0	73.50	73.00	73.00	72.50
C	Toptube length	520	535	550	565	580	600
D	Headtube length	115	127	145	165	185	200
E	Headtube angle (degrees)	71.50	72.50	73.00	73.00	73.00	73.00
F	Fork rake	45	45	45	45	45	45
G	Trail	67.8	61.4	58.3	58.3	58.3	58.3
H	Wheelbase	971	973	980	990	1006	1020
I	Chainstay length	405	405	405	405	405	405
J	Bottom bracket drop	72	72	69.5	69.5	67	67
K	Stack	515	530	546	565	582	596
L	Reach	377	383	388	392	402	412
M	Standover height	746	764	787	808	832	847
N	Handlebar width	380	380	400	400	420	420
O	Stem length	80	90	100	110	110	120
P	Crank length	165.0	165.0	170.0	170.0	172.5	172.5
Q	Wheel size	700C	700C	700C	700C	700C	700C
