Highlight

IMAGINE A QUICK AND AGILE ROAD BIKE BUT WITH GREATER VERSATILITY. WITH FLAT HANDLEBAR POSITIONING, SMOOTH COMPLIANCE AND WIDE TUBELESS TYRES, FASTROAD AR FREES YOU UP TO RIDE PAVED ROADS, BUMPY BIKE PATHS AND EVERYTHING IN BETWEEN.

KEY PERFORMANCE FACTORS

Lightweight efficiency

Advanced Composite frameset and sleek shaping make this model 350 grams lighter than the aluminium version. A stiffer bottom bracket area improves power transfer so you can accelerate and climb faster with less effort.

Smooth, stable ride quality

Flat handlebar frame geometry creates a more upright riding position for confident handling. Powerful disc brakes offer added control in all conditions. And the combination of a D-Fuse composite seatpost and ErgoMax saddle helps smooth out rough roads.

All-road capabilities

With clearance for high-volume tubeless tires (up to 42mm), riders have the freedom and versatility to ride smooth roads, bumpy bike paths or gravel. Single or double chainring setups are available on different models to suit individual riding style and terrain.

SPECIFICATIONS

Sizes

XS, S, M, M/L, L, XL
Colors

Cryo Silver
Frame

Advanced-Grade Composite, flat mount disc, 12x142mm thru-axle
Fork

Advanced-Grade Composite, Full Carbon, OverDrive Steerer, 12x100mm thru-axle, flat mount disc
Shock

N/A
Handlebar

Giant Sport, 0mm rise, 9-degree back sweep, clamp diameter 31.8mm
XS & S: 640mm
M - XL: 680mm
Grips

Giant ErgoContact
Stem

Giant Contact, 8-degree (XS: 70mm, S: 80mm, M: 90mm, M/L: 100mm, L: 100mm, XL: 110mm)
Seatpost

Giant D-Fuse composite, 350mm
Saddle

Giant ErgoContact
Pedals

platform pedal
Shifters

Shimano CUES, SL-U6000-11R, 1x11-speed
Front Derailleur

N/A
Rear Derailleur

Shimano CUES, RD-U6020-11
Brakes

Tektro Hydraulic Disc, HD-M3110, Giant MPH rotors [F]160mm, [R]160mm
Brake Levers

Shimano BL-MT201
Cassette

Shimano CS-LG400-11,11x45
Chain

KMC X11 with Missing Link
Crankset

Shimano CUES, FC-U6030-1, 40T, Silver
XS - M: 170mm,
M/L - L: 172.5mm, L: 172.5mm
XL: 175mm
Bottom Bracket

BB-RS500-PB
Rims

Giant P-R2 Disc, 700C Wheelset, 12mm Thru Axles
Hubs

Giant alloy, 12mm thru-axle
Spokes

Giant P-R2 Disc
Tyres

Giant Gavia Fondo 2, wirebead, tubeless, 700x32c
Extras

tubeless prepared, 42mm max tyre size, double chain ring 50/34T, single chain ring 42T

*All specifications and prices listed are subject to change without notice.

Sizing Guide and Geometry

Sizing to be used as a reference only. Please check with a local authorized dealer to determine the correct size.
Available sizes may vary by country.

Fastroad Advanced AR

		XS	S	M	ML	L	XL
A	SEAT TUBE LENGTH (mm)	435	455	475	495	525	555
B	SEAT TUBE ANGLE	73.5°	73.5°	73.5°	73.0°	73.0°	73.0°
C	TOP TUBE LENGTH (mm)	545	560	575	590	610	630
D	HEAD TUBE LENGTH (mm)	110	130	155	175	200	225
E	HEAD TUBE ANGLE	70.5°	70.5°	71.0°	71.0°	71.5°	71.5°
F	FORK RAKE (mm)	50	50	50	50	50	50
G	TRAIL (mm)	73.7	73.7	70.4	70.4	67.1	67.1
H	WHEELBASE (mm)	1031	1047	1058	1069	1084	1105
I	CHAIN STAY LENGTH (mm)	435	435	435	435	435	435
J	BOTTOM BRACKET DROP (mm)	75	75	75	75	75	75
K	STACK (mm)	533	552	578	597	623	646
L	REACH (mm)	387	396	404	407	419	432
M	STAND OVER HEIGHT (mm)	718	736	756	773	800	826
O	STEM LENGTH (mm)	70	80	90	90	100	110
P	CRANK LENGTH (mm)	170	170	170	172.5	172.5	172.5
Q	WHEEL SIZE	700C	700C	700C	700C	700C	700C
