GIANT ANTHEM ADVANCED SL FRAMESET (7TH GEN)

$5,500.00 Sold out
New
Color: Electrical Storm
Size: M
Doorstep Delivery

Local Delivery: Estimated 1-2 business days.
Third-party Couriers: Estimated 2-5 business days.
Color: Electrical Storm
Size: M

Highlight

THIS PRO-LEVEL XC FLYER PAIRS NEW FLEXPOINT PRO REAR SUSPENSION WITH A SUPERLIGHT FULL COMPOSITE FRAME AND RACE-READY GEOMETRY. IT’S THE ULTIMATE WEAPON FOR TECHNICAL CROSS-COUNTRY TERRAIN.

KEY PERFORMANCE FACTORS

Ultra-efficient

Next-generation Advanced composite mainframe and rear swingarm is 250g lighter than previous version. The bottom bracket area is stiffer for faster acceleration, and a steeper seattube puts the rider in an efficient, front-forward climbing position.

Superior control

All-new FlexPoint Pro suspension delivers 100mm of smooth, active rear travel. The reengineered frameset features modern XC geometry including a slacker 67.5-degree headtube and 110mm suspension fork for technical descents.

29er stability and speed

Frame geometry and suspension are optimized for larger-diameter 29-inch wheels. A longer reach and updated cockpit including a 35mm composite handlebar and alloy stem further boost balance and stability on XC terrain.

SPECIFICATIONS
  • Sizes
    S, M, L, XL
  • Colors
    Electrical Storm
  • Frame
    Advanced-Grade Composite front and rear triangles, 100mm FlexPoint Pro suspension, 12x148mm thru-axle
  • Shock
    Rockshox SIDLUXE

*All specifications and prices listed are subject to change without notice.

Sizing Guide and Geometry

Sizing to be used as a reference only. Please check with a local authorized dealer to determine the correct size.
Available sizes may vary by country.

Anthem Advanced SL (7th Gen)
S (LOW/HIGH) M (LOW/HIGH) L (LOW/HIGH) XL (LOW/HIGH)
A Seattube length 400 420 465 495
B Seattube angle (degrees) 75.5° | 76.0° 75.5° | 76.0° 75.5° | 76.0° 75.5° | 76.0°
C Toptube length 576 | 574 602 | 600 624 | 623 651 | 650
D Headtube length 90 95 105 115
E Headtube angle (degrees) 66.5° | 67.0° 66.5° | 67.0° 66.5° | 67.0° 66.5° | 67.0°
F Fork rake 44 44 44 44
G Trail 116 | 112.2 115.9 | 112.2 115.9 | 112.2 115.9 | 112.2
H Wheelbase 1141 | 1140 1168 | 1167 1192 | 1191 1221 | 1220
I Chainstay length 437 | 435 437 | 435 437 | 435 437 | 435
J Bottom bracket drop 51 | 45 51 | 45 52 | 45 52 | 45
K Stack 602 | 599 607 | 603 616 | 612 626 | 622
L Reach 420 | 425 445 | 450 465 | 470 490 | 495
M Standover height 420 | 425 445 | 450 465 | 470 490 | 495
N Handlebar width 769 | 775 764 | 771 758 | 763 751 | 758
O Stem length 60 70 70 80
P Crank length 170.0 175.0 175.0 175.0
*All measurements shown are in millimetres unless otherwise stated.
